Del-Tron® Mini Posi-Drive™ Stages
$874.00 – $1,062.00
Specifications
Drive: .168 diameter .125 lead screw with anti-backlash nut.
Coupling: Flexible zero backlash coupling. Motor Mount: Accepts Nema 14 motor
Travel: 1″ – 4″ Anti-Friction Slide: Linear ball or crossed roller slide.
Load Capacity: Up to 40lbs.
Configuration: 1, 2 or 3 axis.
Accuracy: Straight line, up to 0.0001″ per inch of travel.
Repeatability: 0.0001″
Finish: Black Anodize. Other finishes on request Also available are special configurations, motor mounts, hand crank actuation, and a variety of leads and diameters .
- Description
- Additional information
- Store Policies
Description
Specifications
Drive: .168 diameter .125 lead screw with anti-backlash nut.
Coupling: Flexible zero backlash coupling. Motor Mount: Accepts Nema 14 motor
Travel: 1″ – 4″ Anti-Friction Slide: Linear ball or crossed roller slide.
Load Capacity: Up to 40lbs.
Configuration: 1, 2 or 3 axis.
Accuracy: Straight line, up to 0.0001″ per inch of travel.
Repeatability: 0.0001″
Finish: Black Anodize. Other finishes on request Also available are special configurations, motor mounts, hand crank actuation, and a variety of leads and diameters .
Additional information
SKU | LSA1-25-C005, LSA1-50-C005, LSA1-75-C005, LSA1-100-C005, LRSA1-25-C005 |
---|
